Input Power
|
AC100V~AC240V 50/60HZ
|
|
Nominal Voltage
|
DC 12V
|
DC 24V
|
|
Charging Voltage
|
Normal Mode = max. DC 14V~15.5V
Snow Mode = max. DC 14.6V~15.7V
Boost Mode = max. DC 16.5V
LiFePO4 Mode = max. DC 14.6V
|
Normal Mode = max. DC 28.8V~30V
Snow Mode = max. DC 29.2V~30V
LiFePO4 Mode = max. DC 29.2V
|
|
Charging Current
|
Lead-acid 1A / 3A / 7A / 10A (Current Selectable)
LiFePO4 5A / 10A (Current Selectable)
|
Lead-acid 1A / 2A / 4A / 6A (Current Selectable)
LiFePO4 3A / 6A (Current Selectable)
|
|
DC Supply
|
DC 13.5V / 5A
|
DC 27V / 5A
|
|
Protection
|
1. Short Circuit Protection
2. Over-temperature Protection
3. Spark Protection
4. Over-charge Protection
5. Over-voltage Protection
6. Reverse Polarity Protection
7. Disconnecting Protection
8. Over-current Protection
|
|
Compatible Battery
|
WET / MF / AGM / EFB / LiFePO4
|
|
Operating Temperature
|
-20~ 40°C , Humidity 90%
|
|
Dimension ( L × W × H )
|
197 x 113 x 61 mm ± 2 mm
|
|
Weight
|
0.95 kgs
|
