Injector Removal and Dismantling Set 21 pcs
Model :
MK910521
CONTENTS :
| Universal joint | M18×1.5 |
| Special bit insert hex 10mm × ø7.6 | 1x special-use Allen SW10 with 7.5 mm bore, 1/2 drive, to remove the fixing ring, for example, Bosch injectors at MB CDI and PSA HDI |
| Special bit insert hex 10mm × ø6.6 | For releasing the internal screw of the CR injectors. |
| Pull Spindle: OT M16×1.0 | For Denso (Toyota 2.2D) |
| Pull Spindle: OT M17×1.0 | For Bosch injectors, e.g., Alfa, BMW, Fiat, MB, PSA, Renault |
| Pull Spindle: OT M20×1.0 | For Denso |
| Pull Spindle: OT M25×1.0 | Siemens injectors, e.g. PSA (DW10) |
| Pull Spindle: OT M27×1.0 | Siemens injectors, e.g. PSA (DW10) |
| Pull Spindle: IT M16×1.5 | Pull Adapter for M16 x1.5 thread, such as used in Facom tools. |
| Pull Spindle: IT M14×1.5 | Internal thread for Bosch / Delphi Injectors, e.g. MB (OM 629/642/646), PSA (DV4 / DW12), VW (CBD), BMW (M47) |
| Pull Spindle: IT M25×0.5 | For Denso |
| Pull Spindle: IT M25×0.75 | For Denso |
| Pull Spindle: IT M27×1.0 | For Siemens, e.g. Citroen C5 / Jumpy / Xsara, Fiat Ducato JTD, Peugeot 206/307/406 / Boxer (2.0 / 2.2 / 2.3 HDI) Mercedes-Benz CDI (except A-Class (Sprinter / Vito) |
| Special socket (25mm) | For Siemens Injectors - 2.0 Hdi (DW Series) As found on PSA, Ford, Toyota etc |
| Special socket (27mm) | For Siemens Piezo Injectors – 2.0 Hdi Piezo (DW Series) As found on PSA etc |
| Special socket (29mm) | For Bosch type injectors – Bosch Cdi / Hdi engines |
| Special socket (30mm) | For Bosch type injectors – Bosch Renault / Nissan 1.9dCi |
| Injector gripper(12MM) | For MB CDI-engines, except Sprinter, Vito and A-class |
| Injector gripper(13.5MM) | For Opel Renault F9Q |
| Injector gripper(16MM) | For Fiat Ducato JTD, Citroen C5, Xsara, Jumpy and Jumper HDI and Peugeot 206, 307, 406, Boxer HDI (2.0, 2.2, 2.3I) |
| Injector gripper(26MM) | For Opel Z19DT / Z19DTH / Z19DTL engines, A20DTH (LBS) / A20DTR (LBY) / A20DTJ (LBX) / A20DTC (LCD) and Fiat 1.9 JTD |
