ALPHA MOTO Motorcycle Air Shock Pump with Gauge Compatible with Harley Davidson 60 PSI
-
RMI-TO-028
-
Stock Available
50pcs/CTN , 14.5KGS, 1.9' CUFT
About this item
- 【ESSENTAIL TOOL】:This premium air shock pump is the essential tool to adjust the compression on your fork for your liking, maximizing your motorcycle's performance by ensuring that your have optimal suspension to keep you in control over rough ground. Maximum 60 psi, which is most commonly used on Harley Davidsons due to lower PSI requirements.
- 【Specification】: The gauge is made of die cast, face dia: 1.5" , reads 0-60 psi (also 100xkPa) , 4.1 Maximum Bar Reading, 2 PSI Increments, overall length is about 9".
- 【BLEEDER BUTTON】:Bleeder button on the side of the gauge allow user to release excess air from over pumping to reach the optimal pressure. Please make sure to gently release the button in a very light motion to allow it function properly as designed, a big push to the button will release the air too fast. (Sometimes, a failed valve could also cause the bleeder button not work properly, sometimes, it requires valve to be replaced to ensure the pump work properly)
- 【NO AIR LOSS Feature】: This air shock pump is equipped with an anti-leak head valve that fits Schrader valves. It can be used for all bikes with air suspensions, including Harley Davidson, and other motorcycles or mountain bikes.
- 【Your Satisfaction Is Our Goal】: We are confident that this air shock pump is the most cost-effective one to get your job done, if you are not 100% satisfied, just contact us, we will work the issue out with you until you are 100% satisfied.
Video For Reference
Authorized.
Alpha Moto is a family owned company based out of beautiful Las Vegas. We have been in business over a decade.
We provide motorcyclists with quality motorcycle tools and parts on the market. We work closely with manufacturers to ensure you getting the value for your money. Our goal is to get your bike on the road asap! You can count on us for good products and our service.
Motorcycle Air Shock Pump
The listing is for one Air shock pump. it is used to adjust air suspension pressure in front or rear suspensions. It can be used on Harley touring Dresser bagger (which use a pneumatic rear suspension system requires to be adjusted during each rider and luggage weight changes), or any motorcycle with air shocks, it also can be used on bicycles.
Specification
gauge is made of die case, face dia: 1.5"
reads 0-60 psi (also 100xkPa).
4.1 Maximum Bar Reading
1 PSI Increment
Handle is made of aluminum 6063, overall length is about 9", takes very little room in your storage bag.
360 degree 180mm long swivel-style hose for easy access
No air escaping coupling
In the swivel head of the hose, there is a small built-in O-ring will seal in the valve stem.
When pump in the air, it presses down and opens the valve stem.
This neat feature will prevent any air from escaping during attaching or removing the pump from the valve stem
(if it doesn't register air when pumping, very likely, you need to replace the valve stem)
Built-in bleeder button
With the built-in air control bleeder button
the user can bleed the excess air from the suspension system until the desired pressure is achieved.
Simple use
- Remove valve stem cap, thread the swivel head of the pump hose onto the valve stem
- Pump the air shock pump, usually pump it up a little higher then the specific PSI you want.
- Use the bleeder button to release excess air in order to reach the desired PSI.
- Remove the pump, the O-ring in the swivel head will prevent any air from escaping out of the fork.
